Up and running with ‘Summit’, our map style for quality relief maps

A few weeks ago we expanded our map collection with views on several continents, all including a crisp shaded relief.

Today I want to talk about our map style we use for these kinds of maps.

‘Summit’ is a map style we have developed specifically for our shaded relief maps. These maps contain several layers with vector elements combined with a bitmap (photo) in the background representing the relief and bathymetry of the map area.

If you want to know more about these maps, I suggest you follow along as I explain those details.

You can grab our FREE map of Middle America (Central America if you like). This map is made in the ‘Summit’ style. Just download the map and open it up in Adobe Illustrator (CS3 and above).

Free Map of Middle America

Free map of Middle America political with shaded relief

Shaded Relief

‘Summit’ maps all have a large and detailed shaded relief in the back. This shaded relief is a JPEG of 6000px wide and is well suited for use in print design, web design and more. At 300dpi, the JPEG is still 20 inches wide. We use ‘pixels’, so it is easy to understand how large the image is.

messages-bubble-information-alternate
You can calculate the size and dpi by thinking about dpi as ‘dots per inch’ or ‘pixels per inch’. So if you need 300dpi, you just divide the width of 6000 pixels by 300 dots (or pixels) and then you get 20 inches.

In an upcoming blog post, I will dive deeper into the difference between pixels and dpi. I will explain why there is no difference in file size or quality between a 300dpi 6000 pixels image and a 72dpi 6000 pixels image.
Take a look at this conversion table to have a clear understanding what 6000 pixels wide really means.

6000 pixels wide

Web (72 dpi) Web Retina (144 dpi) Print (300 dpi)
feet 6.94 3.46 1.66
inch 83.3 41.6 20
meter 2.11 1.05 0.508
centimeter 211.5 105.6 50.8

Shaded relief of Asia

100% view on the shaded relief above (centered on Pakistan)
100% view on the shaded relief above (centered on Pakistan)

Layers

The layers that are present in the maps vary a bit depending on the content. In this map style, we have world maps with country names as well as region maps with lots of cities.
You can’t see it visually, but every country is a vector area that you can select and edit. You can find these country areas on the country layer. Out of the box, the country area has no stroke and no fill.
The grid lines are placed on 20 degrees interval.
Whenever possible, objects have names and we have sorted them in alphabetical order. You can see this in the layers palette.

Font

Example of font PT Sans, used in our map style 'Summit'

Example of font PT Sans, used in our map style 'Summit'
Example of font PT Sans, used in our map style ‘Summit’

The font used in the Summit-style is PT Sans.
For easy install, each map package contains those font files. Just double-click the TTF-files and follow the instructions depending on your operating system.
PT Sans was originally developed for the project ‘Public Types of Russian Federation’. This font was released under a libre license and can be used freely in any project.

Appearance palette showing settings for semi-tranparent stroke around type
Appearance palette showing settings for semi-tranparent stroke around type

If you made maps yourself, you know it can be quite a challenge to make the text readable on top of a colorful background like these shaded reliefs. To be sure the text can be read at all times, we did a small trick with it. By using the appearance palette, we added a stroke of 0,4 pt with an opacity of 30%. This way the text is more separated from the background and much more readable on our shaded relief. Depending on the background you use, it could be a good idea to change those values to have a thicker stroke or less opacity for instance. Just keep in mind that these kinds of effects are there to make the text more readable. In my opinion, it comes down to this: the less noticeable, the better.

messages-bubble-information-alternate
Do you want to create a semi-transparent stroke around text yourself?
Select your text and open up the Appearance Palette. Click on the menu of the palette (top right). Click on ‘Add New Stroke’. Drag this new stroke down (under the line that says ‘Characters’). Dial in your values (stroke and opacity) and you should be all set.
Example of type with semi-transparent stroke in the background
Example of type with semi-transparent stroke in the background

Edit your map

This blog post is not intended to be a comprehensive tutorial on editing vector maps. But still I want to give you a nice color palette that plays well with Summit-maps.

Colors used to give countries a fill in our map style 'Lucid'
Colors used to give countries a fill in our map style ‘Lucid’

It is a set of graphic styles from another map style of ours called Lucid and not a real color palette. These colors are built up out of 7 base colors that have the ‘Inner glow’ effect applied to them.

Lucid Colors
messages-bubble-information-alternate
Want to open these graphic styles in another document? Just go to the graphic styles palette, click on the options button in the upper right, choose ‘Open Graphic Style Library’ and then click on ‘Other Library…’. Now select the file you just downloaded and click OK. The graphic styles should be available now in your graphic styles palette.
Give a country area a color by selecting the graphic style of your choice
Give a country area a color by selecting the graphic style of your choice
Play with blend modes, to achieve some nice effects
Play with blend modes, to achieve some nice effects

Now, select your object (for instance a country area on the layer ‘Country area’) and click on the graphic style you want to use. The graphic style is now applied to the object you just selected. By changing the blend mode in the Transparency palette, you can achieve some nice effects.

File Formats

We have two main map packages in our store: printable and vector. Below I will give you an overview and explanation of the most important file formats in each package. The vector package is the most comprehensive. It contains all the files of the printable package and several layered vector oriented files. By downloading the free map mentioned on top of this post, you get the vector package automatically.

Printable map package Vector map package
JPEG (6000px wide) JPEG (6000px wide)
JPEG medium (3000px wide) JPEG medium (3000px wide)
JPEG small (1500px wide) JPEG small (1500px wide)
JPEG shaded relief only (6000px wide) JPEG shaded relief only (6000px wide)
Non-layered PDF Non-layered PDF
Adobe Illustrator CS3 AI layered file
Adobe Illustrator layered PDF

JPEG 6000px wide, JPEG medium 3000px wide, JPEG small 1500px wide

All JPEGs are in RGB and exported in Photoshop at the highest possible quality. For your convenience we are providing 3 image sizes: full size (6000px wide), medium (3000px wide) and small (1500px wide).

JPEG shaded relief only

The bitmap (photo) of the shaded relief without any vector objects or text on top of it. Great if you want to show only the shaded relief, or useful as a starting point for a custom map from scratch. The density of the pixels is large enough to use in your design for images up to 20 inches wide 300dpi.

Non-layered PDF

The non-layered PDF has the same content as the vector files, except there are no layers present. Text is editable, all vector objects are selectable, but due to the lack of layers it can be hard to edit the map to fit your needs. Lots of edits can be done more easily with the files of the vector version. Nonetheless, this vector PDF is included in every printable map package.

Adobe Illustrator CS3 AI layered file

The best and most extended version of the map. You can open it up with Adobe Illustrator version CS3 and up, some versions of CorelDRAW and other software should be able to open this file in all its glory. Everything is layered and easily selectable and editable. You can resize this map without any loss of quality, although, to have the best possible sharpness of the shaded relief, you need to be aware of its file size. But, as you can see above, 6000px wide is a lot of goodness to work with.

Adobe Illustrator PDF

We are providing this file format to give you more possibilities in using the map in software other than Adobe Illustrator. This PDF is layered, but it depends on the software that you use if you will see those layers

Remarks Adobe Illustrator CS3 EPS

Maps made in other styles also contain an EPS file format. But we had to do something to limit the file size of the actual package you get when purchasing a map. With the presence of a huge shaded relief, we had to drop this EPS-file for our Summit-Maps.
It should be no problem though, as when you purchase a map, you can contact us to obtain a particular file format that is not present in the map package. We will do everything we can to help you out, but we can’t promise that we can deliver every file format out there. Just contact us if you need to.

I hope you will now be up and running with our map style ‘Summit’. If you have some great ideas for editing these maps, or if you want to share your thoughts about this post, or perhaps about our map style ‘Summit’, do so in the comments below.
